SMD Semi-automatic Packaging Machine

Professional for SMT components with packaging ‘easy to operate’ simple and easy to learn; Taiwan Fengwei PLC programming with Tianjin Luo Sheng text control; Walking speed stepper motor control ‘speed free adjustment, UPH:3.6~ 7.2K /hr;

Professional for SMT components with packaging ‘easy to operate simple and easy to learn;
Taiwan Fengwei PLC programming with Tianjin Luo Sheng text control;
Walking speed stepper motor control ‘speed free adjustment, UPH:3.6~ 7.2K /hr;
Pinwheel side hole counting is more accurate with a full check calculator (loaded with counting, missing material detection);
Track width can be adjusted quickly, the width of the packing bearing belt: 8mm~88mm(more than 88mm can be customized);
Manual mounting parts are suitable for 2-6 people at the same time, the work table can be customized and lengthened;
Sealing knife two groups, independent temperature control two groups, reciprocating or continuous sealing, the sliding cylinder is driven sealing knife action is more stable;
Ac 220V power supply, working pressure 0.30-0.60mpa, rated power of the machine 600W:
Can be customized according to customer needs refitted automatic packaging, automatic detection of all white moving packaging machine.

Carrier tape semi-automatic packaging machine operating principle

Semi-automatic packaging machine with belt, including the base, the base also includes a table, chassis and spindle, the base and the table, chassis and spindle mating connection;
The base is provided with a support block, the table is provided with a first turntable, a first positioning roller, a second positioning roller, a groove and a packaging device, the first turntable is provided with a first connecting rod, the first positioning roller is provided with a first connecting block, the second positioning roller is provided with a second connecting block; the chassis is provided with a control panel, a second turntable, a limit roller and a third turntable, the control panel is provided with a display and a control button, the third turntable is provided with a second connecting rod. The second connecting rod is provided on the control panel. The semi-automatic packaging machine is equipped with a first positioning roller and a second positioning roller, which play a role in positioning the packaging belt, so as to avoid disorder and failure of the packaging belt during the packaging process, thus improving the efficiency of the packaging machine.
